How to connect RGB colors LED strip lights?

Views: 0     Author: Site Editor     Publish Time: 2021-06-08      Origin: Site

Since the RGB colors LED strip light is easy to cut on a given cutting line and can be connected at any point between the copper points on the RGB colors LED strip light, the cutting length varies from product to product, so it is a product with a wide range of uses. This article will briefly introduce a guide on cutting and linking RGB colors LED strips. Let us continue reading to learn more.


This passage is going to talk about the followings of connecting RGB colors LED strip light:

(1) How to cut and fix RGB colors LED strip lights?

(2) Steps to connect RGB colors LED strip light

(3) Conclusion



(1) How to cut and fix RGB colors LED strip lights?

The following is a guide to help you cut a RGB colors LED strip light.

1.) When finding a cutting line to cut RGB colors LED strip lights, it is very important to cut only on the given cutting line between the copper points. Cut through the copper point or do not lead to the following part before the copper point.

2.) Cut the RGB colors LED strip light Use a sharp scissors to cut the strip light directly along the given cutting line.

3.) Make sure that the top of the quick connector can only be used when the top is facing upwards. It is very important to determine the polarity of the LED strip light. Sometimes, if the connecting wires at the opposite end may cross, it will cause confusion. This is also very important.

4.) Pull out the black plastic and gently pull out the black plastic sheet about 1/8 inch. Make sure not to pull hard and damage the quick connector.

5.) Peel off 3M Adhesive Strip the tape of 3M Adhesive about 1/4 inch.

6.) Insert the light strip into the quick connector. Insert the strip light into the connector, check the polarity of the wire (the black wire is the positive electrode) and the copper point should be partially visible.

Note: The quick connector can be used on the other end of the ribbon. If you use it on the opposite end, please determine the polarity and pay attention to the color inversion of the wire.

7.) Safety quick connector Use the connector between your four fingers to press the black part tightly.

8.) Test the connection This is what it looks like when installed correctly, now test by connecting the wires to the power supply.

RGB colors LED strip light

(2) Steps to connect RGB colors LED strip light

Briefly introduce how to connect RGB LED lights.

Whether the LED tube is double-ended or single-ended, if both ends are connected, pay attention to the positive and negative poles of the single-ended power supply. But also need to pay attention to the positive and negative poles. First install the current limiting resistor to the negative pole of the power cord. Then separate the positive and negative wires of the LED strip light. Use a peeler to peel off the positive wire of the LED strip. The positive wire of the LED strip after peeling. Be careful not to remove too much peeling. Then connect the negative wire of the power supply to the positive wire of the LED strip. Then connect the negative wire of the LED to the current limiting resistor. This completes the wiring of the LED strip. Finally, turn on the switch and the LED strip light can glow smoothly. In particular, when installing RGB LEDs, you need to correctly connect the three RGB streets of the strip light you want to connect in series, and you cannot install it backwards.



(3) Conclusion

I hope that after reading this article, you will have a better understanding of the connection and installation about RGB colors LED strip lights.

You can consult us for RGB colors LED strip lights. The company focuses on various types of RGB colors LED strip light and other lighting technology. The company has a professional LED lighting design department to provide customers with customized lighting solutions. If you want to know more about our products and services, please contact us!
